100 Metre Coil of 1.5mm 6242Y twin and earth Grey cable
Part No.:
Twin and Earth is a name for a type of Mains Electricity Cable, and is the most common cable for domestic wiring today. Comprising of 1 Live (Brown) and 1 Neutral (Blue) sheathed conductor, and a Earth which is of the CPC type (Circuit Protective Conductor) which is bare. The Overall sheath is of PVC Construction to BS6004.
The 1.5mm Conductors are Solid with the CPC earth being 1.0mm, and rated in normal conditions at around 18 Amps, this particular size is common with very Lighting circuits. Also available in cut lengths, 25m and 50m Coils.
Not suitable for unprotected use outside as the outer sheath are vunerable to attack from UV, however Alkyd paint is enough to protect it from UV.
- Voltage Rating - 300/500 Volts
- Temperature Rating - Maximum +70oC
- Overall Standard - BS6004:2000 Table 8
- COnductor Standard - BS EN 60228
- Insulation Standard - BS EN 50363-3.2005
- Sheath Standard - PVC BS7655-4.2000
- Nominal Overall Dimensions - 4.6mm x8.5mm
