Cut To Metre length Of 6.0mm 3 Core H07RN-F Flexible Rubber Cable
Part No.:
This product is not eligible for return. Find out more
Applications include handling equipment, mobile power supplies, worksites, stage and audio equipment and also dam and port area's. Due to the H07-RNF cables suitability for submersion under water it is also used for drainage and water treatment as well as electric motors and pumps in underwater conditions. Tough and reliable this cable can survive harsh enviroments.
Features And Benefits -
- 6.0mm (84/0.30) x 3 Core Stranded Conductors
- Conductor Colours - Brown, Blue and Green/Yellow
- 450/750 Volt Rating
- 58 Amps Maximum For Cables Set In Air
- 39 Amps Maximum For Cables Fixed To Surface
- Temperature Range -30 to +60oC For cables Fixed
- Temperature Range -15 to +60oC For Cables Flexed/Trailing
- Conductor Standard - Class 5 Flexible to BS EN 60228 (Previously BS6360)
- Insulation Standard - EPR (Ethylene Propylene Rubber) EI4 to BS EN 50363
- Sheath Standard - PCP (Polychloropene) EM2 to BS EN 50363
- Nominal Insulation Thickness - 1.0mm
- Nominal Overall Diameter - 14.78mm
- Weight - 39 Kgs per 100 Metres
- Gland Size - 25.0mm
